The Z-Arm S922 is a highly flexible and mid-range collaborative robot designed for precision automation, assembly, and material handling. With a 5kg payload, a 922mm reach, and ±0.02mm repeatability, it provides seamless integration into manufacturing, electronics, medical, and research environments. Engineered for safe human-robot collaboration, the Z-Arm S922 enhances efficiency, improves consistency, and reduces operational costs for businesses adopting smart automation solutions.

Payload

5kg

Working Range

922mm

Repeatability

±0.02mm

Degree of Freedom

Typical TCP Speed

1m/s

Protection Level

IP54

Installation Orientation

Upright / Vertical Side / Inverted Mounting

Communication

I/O, TCP/IP, Modbus TCP/RTU, PROFINET

Joint Range of Motion

Axis 1: ±175°
Axis 2: +85°, -265°
Axis 3: ±160°
Axis 4: +85°, -265°
Axis 5: ±175°
Axis 6: ±175°

End I/O Port

Digital Input: 2
Digital Output: 2
Analog Input: 1
Analog Output: 1

Use Environment

- Away from vibrations (≤0.5G)
- Avoid corrosive and explosive gases
- Avoid dust, smoke, and water
- Avoid unstable current conditions

Gripper Compatibility

Z-EFG-C35

Z-EFG-C50

Z-EFG-C65

Z-EFG-FS

Z-EFG-L

Z-EFG-R

Custom Automated Machinery Design

The Z-Arm S922 delivers high-speed, precise automation for mid-range payload applications, making it ideal for custom robotic machinery in electronics, medical, and light industrial automation.

Learn More

Robotic Automation

With a 5kg payload and adaptive control, the Z-Arm S922 is designed for safe human-robot collaboration, enhancing precision assembly, small-part handling, and automated quality control.

Learn More

Vision Inspection Systems

By integrating with AI-powered vision technology, the Z-Arm S922 improves real-time defect detection, optical inspection, and automated quality assurance in manufacturing and laboratory settings.

Learn More

Inquiry Form

Get in touch with us for product inquiries, pricing, and technical details.
